High Carrying Capacity Silicone Flexible Cable Oil Resistant Customizable

  High Temperature and Low Temperature Resistant Silicone Rubber Sheath Stranded Copper Conductor Power Cable Multicore Round/Flat 0.6/1KV Ultra Soft Electric Wire. Silicone rubber coated cable has soft, high temperature resistance, low temperature resistance, aging resistance, oil resistance, small bending radius and other characteristics. Suitable for rated AC voltage 0.6/1kv and below the new energy system, mobile equipment and electrical power transmission lines and control, lighting, communication lines.

• Conductor: Stranded multiple thin copper wires
• Sheath: High-performance Silicone Rubber
• Insulation: Silicone Rubber
• Voltage: 0.6/1KV
• Shape: Round/Flat
• No. of Cores: Available in Single Core, 2 Cores, 3Cores, 4Cores, 5Cores, 6Cores, 8Cores and more
• Cross Section: Ranging from 0.75mm to 120mm
• Usage Scenario: Widely used in metallurgy, power, petrochemical, electronics, automobile manufacturing and other industries

Tinned Copper Conductor

The pure copper conductor is electroplated with tin on the surface, which forms a dense "physical barrier", completely preventing the contact between the copper substrate and the external corrosive media, thus avoiding the oxidation and sulfidation reactions of the copper.

The application scenarios of silicone rubber cables are mainly in the fields that have "high requirements for temperature, reliability and environmental adaptability", specifically including:

•    Industrial manufacturing: such as high-temperature equipment like plastic extruders, die-casting machines, furnaces; internal wiring of CNC machines and robots (requiring flexibility + oil resistance), cables for high-temperature environments in textile machinery.
•    New energy field: photovoltaic systems and energy storage equipment.
•    Outdoor and public facilities field: connection cables for street lamps and traffic signals (resistant to ultraviolet rays + resistant to rain), power distribution lines in northern cold regions (resistant to low temperatures).
•    Rail transportation: internal wiring of subway and light rail cars (halogen-free, low-smoke, flame-retardant + resistant to vibration).
• Internal wiring of intelligent devices: such as industrial control cabinets, PLCS (programmable logic controllers), connections of sensors and actuators. The flat form can be flexibly laid in the narrow interior of the equipment (such as cabinet interlayers, component gaps), reducing space occupation.

CHONGQING KEFEI CABLE GROUP CO., LTD.

Chongqing Kefei Cable Group Co., Ltd., focus on R & D and production of rubber cable for 40 years, it is a large enterprise specializing in the production of cables. Our company is committed to the production of various specifications of electrical cables, products covering mining cables, rubber sheath cable series, shield machine special high voltage cable and other series. Especially the flexible cable series, has more than 20 years of exquisite skills, can be customized according to customer requirements of all kinds of special cables.

Our products are sold all over the world, widely used in various fields, such as coal mine, power station, transportation and so on, with excellent quality and excellent after-sales service favored by domestic and foreign customers.

•    Advanced Technology
•    High Quality Design
•    Perfect Testing Equipment
•    Strict Quality Control
•    Mature Process Flow





To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
