Name: High Flexibility Rubber Flexible Cable Small Bending Radius For Industrial Use
Brand: Chongqing Kefei Cable Group Co., Ltd.
SKU: YC/H07rn-f
Price: 0.20 USD
Availability: InStock

Home > Products > Rubber Flexible Cable >

High Flexibility Rubber Flexible Cable Small Bending Radius For Industrial Use

Industrial Rubber Flexible Cable

Rubber Flexible Cable Small Bending Radius

High Flexibility rubber flex cable

Place of Origin:

Chongqing, China

Brand Name:

Ke Fei Te

Certification:

CCC,ISO9001

Model Number:

YC/H07rn-f

Chat Now

Request A Quote

Product Details

Insulation Material:

EPR

Type:

LOW VOLTAGE Cable

Application:

Mainly Used For Power Transmission That Needs To Resist Mechanical Damage, Chemical Erosion Or Adapt To Mobile Scenarios.

Conductor Material:

Stranded Copper Conductor

Jacket:

Durable, Oil-resistant And Weather-resistant Rubber

Size:

6mm,10mm,25mm,35mm,50mm ,70mm 95mm And So On

Product Name:

H07RN-F Rubber Cable

Shape:

Round Wire

Feature:

Flexible,movable, Oil Resistance ,waterproof ,tensile Resistance And So On

Conductor:

Stranded Copper Wire Conductor

Sheath:

Rubber Sheath

Rated Voltage:

450/750V

Core:

Single Core

Filler:

Rope

Highlight:

Industrial Rubber Flexible Cable

Rubber Flexible Cable Small Bending Radius

High Flexibility rubber flex cable

Payment & Shipping Terms

Minimum Order Quantity

500 meters

Price

$0.20-1.80/meters

Packaging Details

wooden drum,wooden pallet,woven bag,plastic pallet

Delivery Time

4-12DAYS

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Single Core Flexible Power Wire H07RN-F Custom Size 2.5 Mm Rubber Cable

Chat Now

H07RN-F Rubber Sheathed Flexible Cable 450/750V EPR Power Cable 1-300mm

Chat Now

H07RN-F 4 Core Rubber Flexible Cable General Purpose Inflaming Retarding

Chat Now

Flexible Movable Oil Resistant H07RN-F Rubber Sheathed Cable For Mobile Equipment

Chat Now

+86 183 0235 8859

regina@cqkfxl.com

Chat Now

Product Description

Flexible Rubber Cable for Frequent Movement and Bending

Our rubber-sheathed copper core power cable is specifically designed for electrical connections requiring frequent movement and bending. These durable cables feature rubber insulation and sheathing for superior flexibility and longevity in demanding applications.

Product Specifications

Conductor: Stranded copper core with multi-strand structure for enhanced flexibility
Insulation: EPR (Ethylene Propylene Rubber) with oil and moisture resistance
Sheath: Durable rubber with wear, oil, and weather resistance
Configuration: Available in single core, 2 cores, 3 cores, 4 cores, and 5 cores
Voltage Rating: 450/750V
Temperature Range: -30°C to +70°C (90℃ max)
Size: 6mm to 150mm and more
Special Features: Flexible, oil resistant, wear resistant, small bending radius, tensile resistant

Applications

Our rubber-sheathed cables withstand mechanical pressure and deformation while maintaining excellent tensile strength and impact resistance. They perform reliably in high-frequency bending and twisting applications, making them ideal for:

Industrial: Mobile equipment including construction machinery and industrial automation systems
Agricultural: Power lines for agricultural machinery and electrification projects
Construction: Temporary power distribution for site equipment and lighting
Special Environments: Port installations, outdoor applications, and high-temperature areas

Technical Characteristics

Temperature Rating:

Fixed: -30°C to +60°C
Fixed protected installations: +85°C
Flexed: -15°C to +60°C
Insulation tested to +90°C

Minimum Bending Radius:

Fixed: 4 x overall diameter
Flexed: 6 x overall diameter

Product Name	H07RN-F Rubber cable
Brand	Ke Fei Te
Model	YC/H07RN-F
Conductor Material	Pure copper conductor (Multiple strands of fine copper wire)
Insulation Material	EPR (Ethylene-Propylene Rubber)
Jacket	General Rubber Sheath
Color	Black
Shape	Round wire
Feature	Flexible, oil resistance, wear resistance, corrosion resistance, soft and tensile resistance

About Chongqing Kefei Cable Group

Chongqing Kefei Cable Group Co., Ltd specializes in R&D and production of rubber cables for 40 years. As a leading cable manufacturer, we produce various electrical cables including mining cables, rubber sheath cable series, and special high voltage cables. Our flexible cable series benefits from over 20 years of expertise, with capability to customize special cables according to customer requirements.

Our products are globally distributed and widely used in coal mines, power stations, transportation and other fields, recognized for excellent quality and after-sales service.

Our Advantages

Advanced Technology
High Quality Design
Perfect Testing Equipment
Strict Quality Control
Mature Process Flow

Production Equipment

Exhibition

Certification

Packing & Delivery

Frequently Asked Questions

Q: Are you a manufacturer or a trading company?

A: We are a production manufacturer. We only produce the best quality, and you can rest assured of the quality.

Q: Can you produce and manufacture products according to customer requirements?

A: Yes, we can customize the product according to your requirements.

Q: How can we guarantee quality?

A: Always a pre-production sample before mass production; Always final Inspection before shipment.

Q: How can i place an order?

A: Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype / email / phone, in case of any delays.
