Name: Copper Core XLPE Insulated PVC Sheathed Low Voltage Power Cable for Industrial Construction
Brand: Chongqing Kefei Cable Group Co., Ltd.
SKU: YJV
Price: 4.80 USD
Availability: InStock

Home > Products > Low Voltage XLPE Cable >

Copper Core XLPE Insulated PVC Sheathed Low Voltage Power Cable for Industrial Construction

Copper Core Power Cable

XLPE Insulated Power Cable

PVC Sheathed Low Voltage Cable

Place of Origin:

Chongqing, China

Brand Name:

Ke Fei Te

Certification:

ISO

Model Number:

YJV

Chat Now

Request A Quote

Product Details

Working Temperature:

70°C

Rated Current:

16A

Insulation Material:

Xlpe

Type:

LOW VOLTAGE

Application:

Power Distribution, Construction, Industrial, Underground

Conductor Material:

Copper

Jacket:

PVC

Size:

Customized, 2.5/4/6/10/16/25/35mm

Product Name:

Xlpe Insulated Low Voltage Power Cable

Shape:

Round Wire

Feature:

Explosion-proof, Flame Retardant, Good Heat Resistance

Conductor:

99.9% Pure Copper

Rated Voltage:

0.6/1 KV

Insulation:

XLPE Insulation

Sheath:

PVC Shealth

Core:

1/2/3/4/3+1/5/3+2/4+1

Highlight:

Copper Core Power Cable

XLPE Insulated Power Cable

PVC Sheathed Low Voltage Cable

Payment & Shipping Terms

Minimum Order Quantity

500 meters

Price

$0.80-9/meters

Packaging Details

wooden drum,wooden pallet

Delivery Time

5-12days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Copper Core XLPE Insulated PVC Sheathed Low Voltage Power Cable for Industrial Construction

Chat Now

Low Voltage Power Cable 0.6kV PVC Sheath 2.5mm To 35mm Xlpe Cable

Chat Now

XLPE Insulated Low Voltage Electrical Cable 0.6kV Underground Low Voltage Wire

Chat Now

Pure Copper Low Voltage XLPE Cable 0.6kV 4cores Low Voltage Electrical Wire

Chat Now

+86 183 0235 8859

regina@cqkfxl.com

Chat Now

Product Description

YJV-1*120mm Copper Core XLPE Insulated PVC Sheathed Industrial Construction Power Cable

0.6/1kV Low Voltage Outdoor/Indoor Cable with XLPE Insulation and PVC Sheath. Copper Core 70℃ Power Cable designed for construction applications with excellent durability and performance characteristics.

Product Quick Details

Conductor: Pure Solid Copper Conductor with low resistance for high efficiency transmission
Insulation: XLPE (Cross Linked Polyethylene) with high insulation resistance, stable performance, strong heat resistance, and large current carrying capacity
Sheath: Flame Retardant PVC (polyvinyl chloride) Material that withstands up to 90℃ high temperature
Rated Voltage: 0.6/1kV
Cable Features: Durable, Low smoke, Explosion-proof, Long service life, Good Conductivity, Tensile Resistance
Usage Scenario: Suitable for short-distance, low-power power transmission, mainly used for power supply of terminal electrical equipment

Key Features

XLPE insulation with PVC sheath for superior protection
High insulation resistance reduces power loss and enhances transmission stability
Solid bare copper conductor for excellent conductivity
Small bending radius and high durability with long service life
Suitable for both indoor and outdoor installations
Can be installed in cable ducts, trenches, or directly buried
Simple structure with no special laying requirements, suitable for various environments

Technical Specifications

Conductor: Pure Solid Copper Core
Insulation: XLPE
Sheath: PVC
Cores: Single core, 2/3/4/5/6 Cores
Voltage: 0.6/1KV
Temperature Rating: -30°C to +70°C (90℃ max)
Cross Section: 1mm, 1.5mm, 2.5mm, 4mm, 6mm, 10mm, 16mm, 25mm, 35mm, 50mm, 70mm, 95mm, 120mm, 150mm and so on

Applications

These cables are ideal for direct burial or installation on trays/ducts, resistant to various construction environments including wear, acid/alkali, cold, sunlight, and aging. The solid copper core provides strong oxidation resistance, energy efficiency, voltage stability, and long service life.

Product Specifications

Product Name	Flexible XLPE Insulation Low Voltage Power Cable
Brand	Ke Fei Te
Model	YJV/YJV22
Conductor Material	Copper conductor
Insulation Material	XLPE
Jacket	PVC
Color	Black
Shape	Round
Feature	Wear-resistant, acid/alkali-resistant, cold sunscreen, anti-aging

About Chongqing Kefei Cable Group Co., Ltd.

Chongqing Kefei Cable Group Co., Ltd. has focused on R&D and production of rubber cable for 40 years, specializing in various electrical cables including mining cables, rubber sheath cable series, and shield machine special high voltage cable series.

Our Advantages

Advanced Technology
High Quality Design
Perfect Testing Equipment
Strict Quality Control
Mature Process Flow

Production Equipment

Certifications

Packing & Delivery

Professional, environmentally friendly, convenient and efficient packaging services to ensure the safety of your goods.

Frequently Asked Questions

How can I place an order?

Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype / email / phone, in case of any delays.

Are you a manufacturer or a trading company?

We are a production manufacturer, producing only the best quality products.

Can you produce and manufacture products according to customer requirements?

Yes, we can customize the product according to your requirements.

How can we guarantee quality?

Always a pre-production sample before mass production; Always final Inspection before shipment.
