Name: 450/750V 3 Core Submersible Power Cable With 16A Rated Current
Brand: Chongqing Kefei Cable Group Co., Ltd.
SKU: JHS
Price: 0.20 USD
Availability: InStock

Home > Products > Submersible Pump Cable >

450/750V 3 Core Submersible Power Cable With 16A Rated Current

3 Core Submersible Power Cable

16A Submersible Power Cable

16A submersible pump cord

Place of Origin:

Chongqing, China

Brand Name:

Ke Fei Te

Model Number:

JHS

Chat Now

Request A Quote

Product Details

Working Temperature:

70°C

Rated Voltage:

450 V

Rated Current:

16A

Insulation Material:

Rubber

Type:

LOW VOLTAGE

Application:

Submersible Pump Cable

Conductor Material:

Annealed Copper Conductor

Jacket:

Rubber

Size:

Customized

Product Name:

Waterproof Submersible Pump Cable

Shape:

Round Wire

Feature:

Waterproof,cold Resistance, Soft ,high Temperature Resistance

Conductor:

Pure Copper

Insulation:

Rubber Insulation

Voltage:

450/750V

Sheath:

Rubber Sheath

Filler:

Rubber

Certificate:

ISO9001/CCC

Core:

3 4 5 Cores

Highlight:

3 Core Submersible Power Cable

16A Submersible Power Cable

16A submersible pump cord

Payment & Shipping Terms

Minimum Order Quantity

500 meters

Price

$0.20-1.80/meters

Water Resistance Submersible Pump Cable Rubber Sheathed High Durability

Chat Now

video

LV Round Flexible Submersible Water Well Pump Wire For Water Conservancy Project

Chat Now

video

0.75mm2~300mm2 Submersible Water Pump Cable Low Voltage Insulation Resistance

Chat Now

video

4 Core Submersible Cable Submersible Pump Cord ISO9001/CCC Certified

Chat Now

+86 183 0235 8859

regina@cqkfxl.com

Chat Now

Product Description

450/750V 3-Core H07RN-F Power Cable Copper Core Flexible Rubber Sheath for Submersible Pumps

450/750V Multi Cores Waterproof H07RN-F Power Cable 3x16mm 3X70mm Copper Core Flexible Rubber Sheath 16A Rated Current for Submersible Pumps

Product Quick Details

Conductor: Stranded multiple thin copper wires
Sheath & Insulation: Rubber
Voltage: 450/750V
Shape: Round
No. of Cores: Available in Single Core, 2 Cores, 3Cores, 4Cores, 5Cores, 6Cores, 8Cores and more
Cross Section: Ranging from 0.75mm to 120mm
Usage Scenario: The waterproof rubber cable has excellent waterproof and electrical insulation properties, and is widely used in fields such as water conservancy, coal mining, underwater operations, ships and ports.
Advantages of Cables: Highly efficient moisture isolation, suitable for damp/underwater environments, and the waterproof cable can reduces various risks at the source by blocking moisture.

Application of Submersible Water Pump Cable

This Submersible Water Pump cable is suitable for various types of the lead wire of submersible motor (lead from underwater to above-water). This product can be equipped with a waterproof joint (it can be supplied completely as request). The features of lead wire are convenient in use, good waterproof property. Even if it exists in external damage, it can also guarantee the motor is not suffered from damage caused by water.

Specification

Product Name	Waterproof Rubber cable
Brand	Ke Fei Te
Model	JHS
Conductor Material	Copper conductor
Insulation Material	Rubber
Jacket	Rubber
Color	Black
Shape	Round wire
Feature	Inflaming retarding, waterproof, cold resistance, high temperature resistance

Company Profile

Chongqing Kefei Cable Group Co., Ltd. focus on R & D and production of rubber cable for 40 years, it is a large enterprise specializing in the production of cables. Our company is committed to the production of various specifications of electrical cables, products covering mining cables, rubber sheath cable series, shield machine special high voltage cable and other series. Especially the flexible cable series, has more than 20 years of exquisite skills, can be customized according to customer requirements of all kinds of special cables.

Our products are sold all over the world, widely used in various fields, such as coal mine, power station, transportation and so on, with excellent quality and excellent after-sales service favored by domestic and foreign customers.

Our Advantages

1. Advanced Technology

2. High Quality Design

3. Perfect Testing Equipment

4. Strict Quality Control

5. Mature Process Flow

Production Equipment
